KSF76

KHF76 SLIPPER & EYE SUSPENSION – OVER/UNDER-SLUNG MECHANICAL SUSPENSION

The KHF76 Mechanical suspension is a heavy-duty slipper and eye design that offers an ideal solution for low-loader trailers working in rough terrain and at high speeds where a low running height is required. Including low-loader trailers, bale trailers & light & medium capacity grain & silage trailers.

The heavy-duty fabricated steel construction ensures a uniform, robust and high-quality finish design, whilst the spring eye design, insures, the axle has a constant connection with the chassis at all, times, making it ideal for rough terrain applications. The KHF76 suspension is available with either standard Ø22mm spring eye pins or Ø25mm heavy-duty spring eye pins. All hangers and equalisers are produced using a 12mm plate insuring the strongest suspension of its type on the market. The suspension design allows for either Under-slung or Over-slung configuration using the same components, making this suspension also suitable for additional applications.

Options are available with various multi-leaf spring options to suit multiple capacities, stability and axle centre requirements.

DESIGN:

• Fabricated Hangers produced from 12mm plate.
• Design allows for Under-slung or Over-slung assembly.
• Slipper & eye design adds stability in rough terrain.
• Ø25mm heavy-duty pins as standard.
• Tandem, tridem and Single axle assemblies available.
