Two Piece Fittings
SAFETY & FLEXIBILITY WITH VOSS HOSE FITTINGS
Hydraulic systems are only as efficient as each individual component. So VOSS Fluid places the same high demands on the quality of its hose fittings as on the rest of the range. This is true for their leakage and assembly reliability as well as their versatility and durability. The synergy between VOSS Fluid hose fittings and other VOSS coupling systems guarantees the right fit for any application.
All components and systems from VOSS are perfectly matched. Uniform values and parameters make assembly easier, more reliable and increase protection against leakage while improving the load capacity. In addition, as the standard VOSS Fluid solutions provide exemplary corrosion protection that has set the benchmark in the market and significantly increase the product service lives.
PRECISION
Precision-engineering solutions developed from decades of competence and expertise.
HIGHEST LEAK-PROOFING
Highest leak-proofing thanks to standardisation of system components.
ASSEMBLY
Efficient assembly reliability thanks to consistent assembly criteria.
CORROSION PROTECTION
Standard, long-service life through maximum corrosion protection with zinc-nickel coating.
VERSATILITY
Versatility with multi-variant product solutions.
FERRULES
3/16” TO 2” DIAMETER
VOSS & FLEXEQUIP FERRULES AVAILABLE FOR 3/16” UP TO 2” HOSE.
Skive and No-skive Ferrules available for different types of hose applications.
FEATURES
- Precision-engineered solutions made from decades of expertise and know-how.
- Perfect alignment between fittings and couplings.
- Standard durability thanks to maximum corrosion protection with a zinc-nickel base.
- PF11EN853-1ST/1SN & EN857-1SC/2SC HOSES SKIVE
- PF12EN853-2ST/2SN & EN856-4SP/R12 HOSES SKIVE
- PF13EN853-2ST/2SN & EN856-4SP/R12 HOSES SKIVE
- PF15EN853-1SC/2SN & EN853-1SC HOSES – NO SKIVE
- PF22EN853-1SN/2SN & R1AT/R2T HOSES – NO SKIVE
- PF23THERMOPLASTIC EN855-R7 & R8 HOSES – NO SKIVE
- PTCPTFE CONVOLUTED TAPE WRAPPED & EXTRUDED
- PTCEPTFE CONVOLUTED EXTRUDED
- PTTBPTFE SMOOTH BORE
BSP FITTINGS
DKR TYPE & DKOR (O-RING) TYPE
DKR are the most common type of Female fitting used in UK & Ireland.
- Hose fittings with BSP thread and 60° taper.
- ISO 12151-6 (ISO 8434-6).
- Ideal for use in agricultural and standard hydraulic applications.
- PF11EN853-1ST/1SN & EN857-1SC/2SC HOSES SKIVE
- PF12EN853-2ST/2SN & EN856-4SP/R12 HOSES SKIVE
- PF13EN853-2ST/2SN & EN856-4SP/R12 HOSES SKIVE
- PF15EN853-1SC/2SN & EN853-1SC HOSES – NO SKIVE
- PF22EN853-1SN/2SN & R1AT/R2T HOSES – NO SKIVE
- PF23THERMOPLASTIC EN855-R7 & R8 HOSES – NO SKIVE
- PTCPTFE CONVOLUTED TAPE WRAPPED & EXTRUDED
- PTCEPTFE CONVOLUTED EXTRUDED
- PTTBPTFE SMOOTH BORE
BANJO BOLTS BSP & METRIC
Ideal for use in Valve blocks on all medium to high-pressure hydraulic applications.
FEATURES
- Banjo ring eye & Bolt fittings with BSP thread.
- Banjo ring eye & Bolt fittings with Metric thread.
- Double-eye bolts for assembling two fittings in tandem.
- RNRBSP RING EYE’S FOR BANJOS
- F15 RBSP BOLT FOR BAJO
- F15BSP DOUBLE EYE BOLT FOR BANJO
- RNMMETRIC BANJOS
- F15 MMETRIC BOLT FOR BANJO
JIC FITTINGS
Widely used in fuel delivery and fluid power applications, especially where high pressure is required.
FEATURES
- Hose fittings with UNF thread and 37°cone (JIC).
- ISO 12151-5 (ISO 8434-2).
- Sometimes referred to as – Joint Industry Council.
- DKJJIC FEMALES 74º CONE FITTINGS
- DKJ9090º JIC FEMALES 74º CONE FITTINGS
- DKJ4545º JIC FEMALES 74º CONE FITTINGS
- AGJJIC MALES 74º CONE – UNF FITTINGS
METRIC FITTINGS
Higher pressure resistance and functional reliability, even under extreme operating conditions.
FEATURES
- Hose fittings with 24° taper & O-ring
- Fit in bore type
- W DIN 3861/ISO 434-1
- ISO 12151-2 (ISO 8434-1)
ADVANTAGES
- Permanent stability thanks to metallic taper coupling on the fitting body and additional soft seal.
- Reliable over-tightening protection.
- Reduced work effort thanks to reduced tightening distances & tightening forces.
- Maximum tightness thanks to embedded FKM O-ring (standard).
- Improved leak-proofing & precision seal.
- Easy, fast and reliable installation
- Repeat installations can be performed frequently without any issues.
DKOL METRIC LIGHT FITTINGS
- DKOLMETRIC FEMALES 24º CONE DIN 3865 LIGHT WITH ‘O’ RING
- DKOL 9090º METRIC FEMALES 24º CONE DIN 3865 LIGHT WITH ‘O’ RING
- DKOL 4545º METRIC FEMALES 24º CONE DIN 3865 LIGHT WITH ‘O’ RING
- CELMALES 74º DIN 3861 LIGHT
- F15 MMETRIC BOLT FOR BANJO
DKOS METRIC HEAVY FITTINGS
- DKOSMETRIC FEMALES 24º CONE DIN 3865 HEAVY WITH ‘O’ RING
- DK0S 9090º METRIC FEMALES 24º CONE DIN 3865 HEAVY WITH ‘O’ RING
- DKOS 4545º METRIC FEMALES 24º CONE DIN 3865 HEAVY WITH ‘O’ RING
- CESMALES 74º DIN 3861 HEAVY
STANDPIPE FITTINGS
Can be used in tandem with a DIN compression fitting to connect a Steel Tube and flexible hose assembly.
FEATURES
- Hose fittings with pipe attachment for cutting rings.
- ISO 8434-1
- Normally referred to as -Standpipes.
- BELSTANDPIPES FOR DIN 2353 FITTINGS LIGHT
- BEL 9090º STANDPIPES FOR DIN 2353 FITTINGS LIGHT
- BESSTANDPIPES FOR DIN 2353 FITTINGS HEAVY
- BES 9090º STANDPIPES FOR DIN 2353 FITTINGS HEAVY
ORFS FITTINGS
ORFS (O-Ring Face Seal) fittings have a straight thread and a flat face with an O-ring groove machined in the flat face. Sealing takes place by compressing the O-ring onto the flat face of the female connector.
FEATURES
- Exceeds SAE J1453 and ISO 8434-3.
- Sealing takes place by compressing the O-ring.
- Provides a connection between steel tubing and SAE J1926/ ISO 11926-1 O-Ring Ports.
ADVANTAGES
- Reliable over-tightening protection.
- Reduced work effort thanks to reduced tightening distances & tightening forces.
- Maximum tightness thanks to embedded FKM O-ring (standard).
- Improved leak-proofing & precision seal.
- Higher pressure resistance & functional reliability, even under extreme operating conditions.
- Easy, fast & reliable installation repeat installations can be performed frequently without any issues.
- ORFSFACE SEAL FEMALE FITTINGS ISO 12151-1 (ISO 8434-3)
- ORFS 90FACE SEAL 90º FEMALE FITTINGS ISO 12151-1 (ISO 8434-3)
- ORFS 45FACE SEAL 45º FEMALE FITTINGS ISO 12151-1 (ISO 8434-3)
- AORFSFACE SEAL MALE FITTINGS ISO 12151-1 (ISO 8434-3)
JETWASH FITTINGS
Jet washing fittings used on all high-pressure cleaning machines.
FEATURES
- Plastic coated for ease of removal.
- Standard M22 x 1.5 thread.
- DKKJETWASH COUPLING COMPLETE
- DKKLJETWASH COUPLING COMPLETE (LONG TYPE)
- KF - KM ADAPTORS22MM KARCHER TO BSP FEMALE OR MALE
SAE FITTINGS
Can be used in tandem with split clamps. The split clamps make it easy to assemble the connection in close quarters.
They also make removal of the flange head component, such as the hose assembly, easy by loosening all four bolts. Due to this usage of the O-ring, flanges with O-rings has an advantage over metal to metal flanges as all-metal flanges are more prone to leakage because they must be tightened to a higher, yet narrower torque range.
FEATURES
- Hose fittings with SAE flange
- FL3 Standard series (3000 PSI)
- FL6 Standard series (6000 PSI)
- ISO 12151-3 (ISO 6162-1 and ISO 6162-2)
- SAE J518
ADVANTAGES
- Leak free Advantages
- Higher pressure resistance & functional reliability, even under extreme operating conditions.
- Ease of assembly.
- Maximum tightness thanks to FKM O-ring (standard).
- Reliable over-tightening protection.
- Repeat installations can be performed frequently without any issues.
SAE 3000 PSI FLANGE FITTINGS
- FL3SAE J518 FLANGES 3000 PSI FLANGE FITTINGS (CODE61)
- FL3 9090º SAE J518 FLANGES 3000 PSI FITTINGS (CODE61)
- FL3 4545º SAE J518 FLANGES 3000 PSI FITTINGS (CODE61)
- FSC3FLANGE SPLIT CLAMPS 3000 PSI (CODE61)
SAE 6000 PSI FLANGE FITTINGS
- FL6SAE J518 FLANGES 3000 PSI FLANGE FITTINGS (CODE61)
- FL6 9090º SAE J518 FLANGES 6000 PSI FITTINGS (CODE62)
- FL6 4545º SAE J518 FLANGES 6000 PSI FITTINGS (CODE62)
- FSC6FLANGE SPLIT CLAMPS 6000 PSI (CODE62)
CAT FLANGE FITTINGS
Can be used in tandem with split clamps. The split clamps make it easy to assemble the connection in close quarters.
FEATURES
- Hose fittings with CAT flange.
- FLCAT High-Pressure Series (9000 PSI)
- ISO 12151-3 (ISO 6162-1)
- SAE J518
ADVANTAGES
- Leak free Advantages.
- Higher pressure resistance and functional reliability, even under extreme operating conditions.
- Ease of assembly.
- Maximum tightness thanks to FKM O-ring (standard).
- Reliable over-tightening protection.
- Repeat installations can be performed frequently without any issues.
- FLCFLANGES TYPE CAT
- FLC 9090º FLANGES TYPE CAT
- FCL 4545º FLANCES TYPE CAT
