Interlock Fittings

Interlock Fittings

SAFETY & FLEXIBILITY WITH VOSS HOSE FITTINGS

Hydraulic systems are only as efficient as each individual component. So VOSS Fluid places the same high demands on the quality of its hose fittings as on the rest of the range. This is true for their leakage and assembly reliability as well as their versatility and durability. The synergy between VOSS Fluid hose fittings and other VOSS coupling systems guarantees the right fit for any application.

All components and systems from VOSS are perfectly matched. Uniform values and parameters make assembly easier, more reliable and increase protection against leakage while improving the load capacity. In addition, as the standard VOSS Fluid solutions provide exemplary corrosion protection that has set the benchmark in the market and significantly increase the product service lives.

INTERLOCK FERRULES

VOSS Interlock ferrules are available for 3/4″ up to 2″ hose.

Skive Ferrules are available for different types of hose applications.

  • MPF3
    FOR HOSE TYPES: DIN 20023-4SH EN 856-4SH SAE 100R13 EN856-R13 SAE 100R15
  • MPF4
    FOR HOSE TYPES: SAE 100R13 EN856-R13 SAE 100R15

METRIC HEAVY INTERLOCK FITTINGS

19 to 32mm diameter – Interlock hose fittings with metric thread and 24º taper.

  • MCES - INTERLOCK MALES 24º DIN 3861
    FOR HOSE TYPES: DIN 20023-4SH 856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MDKOS - INTERLOCK METRIC FEMALES 24º CONE 'O' RING
    FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MDKOS90 - INTERLOCK 90º METRIC FEMALES 24º CONE 'O' RING
    FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MDKOS45 - INTERLOCK 45º METRIC FEMALES 24º CONE 'O' RING
    FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15

BSP (O-RING) TYPE INTERLOCK FITTINGS

3/4″ to 2″ diameter – Improved leak-proofing and precision seal. Higher pressure resistance and functional reliability, even under extreme operating conditions.

  • MAGR - INTERLOCK BSP 60º CONE MALE
    FOR HOSE TYPES: DIN 20023-4SH EN 856-4SH SAE 100R13 SAE 100R15
  • MDKOR - INTERLOCK BSP FEMALES 60º CONE
    FOR HOSE TYPES: DIN 20023-4SH EN 856-4SH SAE 100R13 EN 856-R13 SAE 100R15
  • MDKOR 90 - INTERLOCK 90º BSP FEMALES 60º CONE 'O' RING
    FOR HOSE TYPES: DIN 20023-4SH EN 856-4SH SAE 100R13 EN 856-R13 SAE 100R15
  • MDKOR 45 - INTERLOCK 45º BSP FEMALES 24º CONE 'O' RING
    FOR HOSE TYPES: DIN 20023-4SH EN 856-4SH SAE 100R13 EN 856-R13 SAE 100R15

JIC INTERLOCK FITTINGS

  • MAGJ - INTERLOCK JIC 74º UNF-UN MALE
    FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MDKOJ - INTERLOCK FEMALES JIC 74º CONE WITH 'O' RING
    FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MDKOJ 90º - INTERLOCK 90º FEMALES 74º CONE WITH 'O' RING
    FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MDKOJ 45º - INTERLOCK 45º FEMALES 74º CONE WITH 'O' RING
    FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15

ORFS & NPT INTERLOCK FITTINGS

19 – 38mm 3/42 to 2″ – ORFS Female Interlock, NPTF Male Fittings

  • MORFS - INTERLOCK FACE SEAL FEMALE FITTINGS
    ISO 12151-1 (ISO 8434-3) FOR HOSE TYPES: DIN 20023-4SH EN 856-4SH SAE 100R13 EN856-R13 SAE 100R15
  • MORFS 90 - INTERLOCK FACE SEAL FEMALE 90º FITTINGS
    ISO 12151-1 (ISO 8434-3) FOR HOSE TYPES: DIN 20023-4SH EN 856-4SH SAE 100R13 EN856-R13 SAE 100R15
  • MORFS 45 - INTERLOCK FACE SEAL FEMALE 45º FITTINGS
    ISO 12151-1 (ISO 8434-3) FOR HOSE TYPES: DIN 20023-4SH EN 856-4SH SAE 100R13 EN856-R13 SAE 100R15
  • MAGN - INTERLOCK NPTF FOR HOSES
    FOR HOSE TYPES: DIN 20023-4SH EN 856-4SH SAE 100R13 EN856-R13 SAE 100R15

FLANGE INTERLOCK FITTINGS

3/4″ to 2″ diameter – Hose Fittings with SAE flange

Standard series MFL 3 (3,000 PSI), ISO 12151-3 (ISO 6162-1), High-Pressure series MFL 6 (6,000 PSI), ISO 12151-3 (ISO 6162-2), High-Pressure series MFL CAT (9,000 PSI), ISO 12151-3 (ISO 6162-2).

  • MFL3 - INTERLOCK SAE J518 FLANGES 3000 PSI
    (CODE 61) FOR HOSES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MFL3 90 - INTERLOCK 90º SAE J518 FLANGES 3000 PSI
    (CODE 61) FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MFL3 45 - INTERLOCK 45º SAE J518 FLANGES 3000 PSI
    (CODE 61) FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MFL6 - INTERLOCK SAE J518 FLANGES 6000 PSI
    (CODE 62) FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MFL6 90 - INTERLOCK 90º SAE J518 FLANGES 6000 PSI
    (CODE 62) FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MFL6 45 - INTERLOCK 45º SAE J518 FLANGES 6000 PSI
    (CODE 62) FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MFLC - INTERLOCK FLANGES TYPE CAT
    FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MFLC 90 - INTERLOCK 90º FLANGES TYPE CAT
    FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
  • MFLC 45 - INTERLOCK 45º FLANGES TYPE CAT
    FOR HOSE TYPES: DIN 20023-4SH EN856-4SH SAE 100R13 EN856-R13, SAE 100R15
