Cogged Wedge Belts

COGGED WEDGE V-BELTS

The wedge cogged or Moulded Raw Edge Cogged Belt is a V-Belt with moulded teeth on its inner surface.

The toothed belt offers more flexibility compared to the Wrap construction Belts as the tooth profile allows the accumulation of air pockets into it, which acts as a heat absorber and prevents the temperature of the drive increasing during operation.

The teeth run perpendicular to the belt length and reduce the bending stress over the belt, they run cooler, last longer, and have a substantial operational efficiency compared to Wrap construction Belts. Toothed Belts can be used over the same pulleys as equivalently rated Wrap construction Belt Pulley. Toothed Belts are used in a wide array of mechanical devices, where high power transmission is desired.

PIX offers a wide range of toothed Belts of various profiles, such as; ZX, AX, BX, CX, DX; Classical sections. XPZ, XPA, XPB, XPC, Wedge Belt sections. 3VX, 5VX, 8VX; Narrow sections and 2LX, 3LX, 4LX, 5LX; Light-duty sections.

REC XPZ COGGED WEDGE

SPECIFICATIONS

Belt Length Conversion Factors:

  • Lp to La – 13mm
  • Li to Lp – 37mm
  • Li to La – 50mm



Manufacturing Range from:

  • 21.5 to 200 inches
  • 550 to 5000 mm

Nominal Length (How the belt reference is arrived at)

Pitch length (Lp) in inches (sizes less than 100″ prefixed with zero)

Other sizes available to special order – please speak to our sales team for a quotation.

Recommended minimum pulley diameter: 63mm

Belt weight per metre (kg): 0.07

REC XPA COGGED WEDGE

SPECIFICATIONS

Belt Length Conversion Factors:

  • Lp to La – 18mm
  • Li to Lp – 45mm
  • Li to La – 63mm



Manufacturing Range from:

  • 21.5 to 200 inches
  • 550 to 5000 mm

Nominal Length (How the belt reference is arrived at)

Pitch length (Lp) in inches (sizes less than 100″ prefixed with zero)

Other sizes available to special order – please speak to our sales team for a quotation.

Recommended minimum pulley diameter: 71mm

Belt weight per metre (kg): 0.11

REC XPB COGGED WEDGE

SPECIFICATIONS

Belt Length Conversion Factors:

  • Lp to La – 28mm
  • Li to Lp – 60mm
  • Li to La – 88mm



Manufacturing Range from:

  • 31 to 927 inches
  • 787 to 23546 mm

Nominal Length (How the belt reference is arrived at)

Pitch length (Lp) in inches (sizes less than 100″ prefixed with zero)

Other sizes available to special order – please speak to our sales team for a quotation.

Recommended minimum pulley diameter: 112mm

Belt weight per metre (kg): 0.20

REC XPC COGGED WEDGE

SPECIFICATIONS

Belt Length Conversion Factors:

  • Lp to La – 30mm
  • Li to Lp – 83mm
  • Li to La – 113mm



Manufacturing Range from:

  • 21.5 to 200 inches
  • 550 to 5000 mm

Nominal Length (How the belt reference is arrived at)

Pitch length (Lp) in inches (sizes less than 100″ prefixed with zero)

Other sizes available to special order – please speak to our sales team for a quotation.

Recommended minimum pulley diameter: 180mm

Belt weight per metre (kg): 0.32

3VX COGGED WEDGE

SPECIFICATIONS

Belt Length Conversion Factors:

  • Lp to La – 53mm
  • Li to Lp – 92mm
  • Li to La – 145mm



Manufacturing Range from:

  • 90 to 930 inches
  • 2286 to 23622 mm

Nominal Length (How the belt reference is arrived at)

Pitch length (Lp) in inches (sizes less than 100″ prefixed with zero)

Other sizes available to special order – please speak to our sales team for a quotation.

Recommended minimum pulley diameter: 500mm

Belt weight per metre (kg): 0.95

5VX COGGED WEDGE

SPECIFICATIONS

Belt Length Conversion Factors:

  • Lp to La – 39mm
  • Li to Lp – 61mm
  • Li to La – 100mm



Manufacturing Range from:

  • 57 to 361 inches
  • 1488 to 9169 mm

Nominal Length (How the belt reference is arrived at)

Pitch length (Lp) in inches (sizes less than 100″ prefixed with zero)

Other sizes available to special order – please speak to our sales team for a quotation.

Recommended minimum pulley diameter: 250mm

Belt weight per metre (kg): 0.67
